Transceptor de fibra óptica SFP CBO TN-SFP-LXB11T-BO 1250 Mbit/s 1550 nm monofibra

The BlueOptics SFP optical transceiver TN-SFP-LXB11T-BO is a compact, hot-pluggable module that supports a 1250 Mbit/s data rate and operates at a 1550 nm wavelength for single-fiber links. Designed to fit standard SFP slots, this transceiver provides a space-saving solution for long-distance optical connections in telecom and networking equipment such as switches, routers and media converters. Its single-fiber design enables bidirectional transmission over one optical fiber, reducing cabling complexity for point-to-point links.

Advantages

This SFP module offers reliable long-reach performance at 1550 nm and supports industry-standard SFP form factor for straightforward integration. The hot-pluggable design allows installation and replacement without powering down the host device. Its compact size and single-fiber capability make it suitable for installations where fiber availability is limited or where minimizing fiber runs is a priority.

Suitable for

• Long-distance fiber links between network sites
• Upgrading switches, routers or media converters with single-fiber connectivity
• Telecom and ISP backbone or access network segments
• Point-to-point optical links where fiber count must be minimized

Key specifications

• Data rate: 1250 Mbit/s
• Operating wavelength: 1550 nm
• Single-fiber (bi-directional) operation
• Form factor: SFP (small form-factor pluggable)
• Hot-pluggable module compatible with standard SFP slots

How to use

Insert the transceiver into an available SFP slot on a compatible switch, router or media converter until it seats firmly and the retaining mechanism engages. Connect the single fiber cable with the appropriate duplex or single-fiber connector and ensure correct TX/RX orientation for bidirectional operation. After installation, verify link LEDs and configure the host device interface settings as required for the 1250 Mbit/s data rate. For removal, power down the interface if recommended by the host device or use the hot-plug capability to extract the module carefully following the device vendor's instructions.

Ieteikumi par lietošanu

The transceiver should be handled by trained personnel, avoiding direct exposure of optical ports to contamination; use dust caps when ports are unused and ensure connectors are cleaned before mating.
