Transceptor SFP+ CBO SFP-10G-BX-D 10G 1310nm/1490nm

The SFP+ Transceiver CBO SFP-10G-BX-D 10G 1310nm/1490nm is a compact, hot-pluggable optical module designed for 10 Gigabit Ethernet links. It provides bi-directional transmission over a single optical fiber by using a duplex wavelength pair (1310 nm for one direction and 1490 nm for the opposite direction). The module conforms to the SFP+ form factor and is intended for use in fiber-optic links within data center interconnects, metro and carrier networks, and other network equipment that accepts SFP+ modules.

Advantages

The module supports a 10 Gbps data rate while enabling single-fiber bi-directional connectivity, reducing cabling complexity and fiber strand requirements. Its SFP+ form factor ensures compatibility with a wide range of switches, routers and transceivers that accept standard SFP+ modules. Hot-pluggable design allows insertion and removal without powering down equipment, simplifying maintenance and upgrades. The optical wavelength pairing provides clear directional separation for reliable full-duplex communication over a single fiber.

Suitable for

• Data center interconnects where fiber conservation and high throughput are required
• Metro Ethernet and carrier access networks needing compact 10 Gbps links
• Network equipment with SFP+ ports such as switches, routers and media converters
• Upgrading existing fiber links to 10 Gigabit capacity without adding additional fiber strands

Key specifications

• Form factor: SFP+
• Data rate: 10 Gbps
• Transmit wavelength: 1310 nm (one direction)
• Receive wavelength: 1490 nm (opposite direction)
• Transmission medium: Single-mode fiber, single-fiber bi-directional (BiDi)
• Interface: LC connector
• Hot-pluggable: Yes

How to use

Insert the SFP+ transceiver into an SFP+ socket on compatible network equipment until it locks into place. Connect a single-mode fiber cable with LC connectors, ensuring the transmit and receive ends are correctly matched to the corresponding wavelengths on the remote end. Verify link status through the host device management interface and monitor signal indicators or alarms. For removal, gently disengage the transceiver latch and pull the module straight out to avoid connector damage.

Recommendations

Use single-mode fiber rated for the intended link distance and ensure proper polishing and cleanliness of LC connectors to maintain signal quality. Confirm compatibility of host equipment with SFP+ BiDi modules and check port settings (speed and duplex) in the network device. Avoid excessive bending of fiber cables and follow electrostatic discharge (ESD) precautions when handling the transceiver.
