Broca SDS plus Bosch 2608901762 Broca para martillo Clean 10×100×225 mm

The Bosch SDS plus Hammerbohrer Clean 10×100×225 mm is a rotary hammer drill bit designed for drilling in concrete and masonry with SDS plus chuck rotary hammer drills. The 10 mm diameter and 100 mm working length provide a balance between compact size and effective drilling depth, while the 225 mm total length gives reach in confined or deep drill points. The Clean design improves dust removal during drilling, helping to keep the hole clearer and support continuous drilling performance. The bit is supplied without a hose adapter and is intended for use with compatible SDS plus rotary hammers.

Advantages

The Bosch Hammerbohrer Clean combines a hardened tip geometry and a flute design that promotes efficient removal of dust and debris from the hole. Its SDS plus shank ensures secure fitting and quick bit changes in compatible rotary hammers. The combination of a 10 mm diameter and 100 mm working length makes the bit suitable for drilling anchor holes, dowel holes and through-holes in standard concrete and masonry. The tool steel construction and precision ground cutting edges provide consistent hole quality and reliable service life when used for the intended materials.

Suitable for

• Drilling anchor and dowel holes in concrete
• Making through-holes in brick and masonry
• General fixing and installation tasks that require 10 mm holes
• Use with SDS plus rotary hammer drills

Key specifications

• Shank type: SDS plus
• Diameter: 10 mm
• Working length (drilling depth): 100 mm
• Total length: 225 mm
• Material compatibility: concrete, masonry
• Design feature: Clean flute for improved dust removal

How to use

Secure the rotary hammer drill and insert the SDS plus shank of the bit until it locks in the chuck according to the drill manufacturer's instructions. Select the rotary hammer mode suitable for concrete or masonry and start drilling at low speed to create a guide point, then increase to working speed while applying steady axial pressure. Withdraw the bit periodically to clear accumulated dust and allow the Clean flute design to evacuate debris. Do not use the bit for metal or wood drilling; use appropriate bits for those materials.

Recommendations

For best results, wear appropriate personal protective equipment including eye protection, gloves and a dust mask or respirator when drilling. If a dust extraction system is available, use it with the rotary hammer to reduce airborne dust. Match drill speed and pressure to the material hardness and avoid excessive side loads to extend bit life.
