BRÜDER MANNESMANN Alicates de crimpar especiales para conectores aislados (1092-S)

This crimping tool is purpose-built for insulated terminals and connectors, delivering consistent trapezoidal crimps across three dedicated positions. Unlike generic pliers, it features a ratchet mechanism that guarantees uniform pressure for every connection, with a release function to correct misplaced crimps. The burnished high-grade special tool steel head and multi-component grips provide durability and comfort for professional use.

Highlights

• Crimps insulated terminals and connectors from 0.5 to 6.0 mm² (20–10 AWG)
• Three colour-coded crimping positions: red (0.5–1.0 mm²), blue (1.5–2.5 mm²), yellow (4.0–6.0 mm²)
• Ratchet mechanism ensures consistent crimping pressure; release function prevents errors
• Burnished special tool steel head and multi-component grips for long service life

In daily use

Select the position matching the terminal colour, insert the stripped wire and terminal, and squeeze until the ratchet releases. The trapezoidal profile creates a secure, gas-tight connection on ring terminals, spade terminals, and butt connectors. The 220 mm length offers ample leverage, while the release lever allows you to open the jaws mid-cycle if needed.

Full specifications

• Application: Insulated terminals and connectors
• Crimping capacity: 0.5–6.0 mm² (20–10 AWG)
• Crimping positions: 3 (red, blue, yellow)
• Crimping profile: Trapezoidal
• Tool material: High-grade special tool steel
• Handle material: Multi-component grips
• Tool finish: Burnished
• Length: 220 mm
• Ratchet mechanism: Yes
• Release function: Yes
• Standards compliance: DIN EN 60352-2

Final note

A reliable, professional-grade crimping tool for insulated connectors, built to deliver repeatable results.
