BUSCH-JAEGER 0230-102 base de conexión de antena, 2 salidas, toma final, blanco 2CKA000230A1554

Install a clean TV and radio connection point in a living room or bedroom wall with the BUSCH-JAEGER 0230-102 antenna socket insert. This flush-mounted end socket provides two outputs: an IEC male for TV and an IEC female for FM radio, both with screw terminals for secure wiring.

Key specifications

• Socket type: end socket (Stichdose)
• Number of outputs: 2 (TV + radio)
• TV frequency range: 5 – 862 MHz
• Radio frequency range: 87.5 – 108 MHz
• Insertion loss: 1.5 dB (TV and radio)
• Return loss: >10 dB
• Decoupling TV/radio: >20 dB
• Impedance: 75 Ohm
• Shielding effectiveness: >75 dB
• Mounting type: flush-mounted
• Connection method: screw terminals
• Material: thermoplastic (PC/ABS)
• Colour: white
• Compatible with Busch-Jaeger switch ranges: basicLINE, future® linear, carat®, solo®
• Application: terrestrial TV (DVB-T/T2), cable TV (DVB-C), FM radio

Why choose it

This insert delivers low insertion loss and high shielding to maintain signal quality for both television and radio. Its 75-Ohm impedance matches standard coaxial cabling, and the screw terminals ensure a reliable connection. The white thermoplastic housing blends with common wall plates.

Ideal use cases

• Residential TV and radio wall outlets in living rooms, bedrooms, and home offices.
• Distribution of terrestrial or cable TV signals to a single end point.
• Retrofit or new installations using Busch-Jaeger switch ranges.

Good to know

The insert is designed for flush mounting in standard wall boxes and fits Busch-Jaeger cover frames. It supports both DVB-T/T2 and DVB-C signals, making it suitable for most European TV reception systems.
