Busch-Jaeger Set de radiofrecuencia confort 62762 UJ-214-WL (2CKA006200A0191)

Control blinds, shutters, and lighting wirelessly with the Busch-Jaeger Wireless Comfort Set. Operating on the 868.3 MHz frequency, this set includes a flush-mounted blind/shutter control insert and a battery-powered 2-gang wall transmitter for flexible control.

Overview

The Busch-Jaeger Set Komfort wireless 62762 UJ-214-WL provides a complete solution for wireless control of blinds, shutters, and lighting. The set includes a flush-mounted insert with a switching capacity of 3 A for motors and 10 A for ohmic loads, and a surface-mounted wall transmitter with two channels. The transmitter is battery-operated and can be fixed with screws or adhesive. Cover plates in Alpine White (RAL 9010) are included, compatible with various Busch-Jaeger switch ranges.

What stands out

• Wireless control on 868.3 MHz frequency
• Includes flush-mounted insert and 2-gang wall transmitter
• Battery-operated transmitter for flexible placement
• Compatible with multiple Busch-Jaeger switch ranges

Technical details

• Operating voltage (insert): 230 V AC, 50 Hz
• Switching capacity: 3 A (cos φ = 0.6) for motors, 10 A (cos φ = 1) for ohmic loads
• Transmitter power supply: battery (e.g., 1x CR2032)
• Number of channels: 2
• Wireless range: up to 30 m indoors, up to 100 m open field
• Colour: Alpine White (RAL 9010)
• Operating temperature: 0 °C to +45 °C

Our verdict

A versatile wireless control set for modern home automation, offering reliable operation and easy installation.
