Cable Datalogic CAB-412 USB Type A recto

CAB-412 USB Type A straight cable, 2 meters (6') long, designed for direct connection to Datalogic handheld scanners and imagers such as Gryphon, Dragon, Lynx, Heron and Touch models. The cable provides a standard USB Type A plug and supports devices that use either a power-off terminal or an external power supply. For systems requiring a base adapter cable (indirect connection) — for example some IBM and clone-based PCs with Diamond D531 or Diamond DLL2020 — use the Datalogic part 90A051500.

Advantages

The Datalogic CAB-412 offers a reliable, straight USB Type A connection in a 2 m length suitable for typical retail and industrial workstations. It is compatible with multiple Datalogic models and supports both direct-connect setups and indirect-connect configurations when used with the specified base adapter. The cable uses a standard USB interface for easy integration with IBM PC and PC clone systems.

Suitable for

• Connecting Gryphon, Dragon, Lynx, Heron and Touch series scanners to a PC
• Retail point-of-sale terminals and checkout counters
• Warehouse and inventory stations requiring a 2 m USB cable
• Setups needing either a power-off terminal or an external power supply

Key specifications

• Manufacturer: Datalogic
• Model / MPN: 90A051902 (CAB-412)
• Length: 2 meters (6')
• Connector: USB Type A straight (plug)
• Compatibility: Gryphon, Dragon, Lynx, Heron, Touch series; IBM PC and PC clones
• Indirect-connect option: requires base adaptor cable part 90A051500 for Diamond D531 / DLL2020 bases
• EAN: 5711045052743

How to use

Connect the USB Type A plug of the CAB-412 to an available USB port on the host PC. Attach the other end to the scanner’s interface according to the scanner’s connector instructions. If the scanner or base requires external power, connect the external power supply as specified by the device documentation. For IBM or clone systems using Diamond D531 or DLL2020 bases, fit the 90A051500 base adaptor cable between the base and host to enable indirect connection.

Recommendations

Use the cable in environments where a fixed-length, straight USB connection is appropriate. Avoid sharp bends and excessive strain at the connectors. For indirect connections or specific base compatibility, ensure you have the correct adaptor part (90A051500) before installation.
