Cable Direct Attach Copper DAC QSFP BlueLAN BlueOptics SC252501K3M30 compatible con Molex 74757-2301, 40GBASE-CR4, 30AWG, 3m (74757-2301-BL)

The BlueOptics Molex 74757-2301 compatible BlueLAN DAC QSFP SC252501K3M30 is a high-performance direct attach copper (DAC) cable designed for 40 Gbps data transmission. It provides a cost-effective, low-latency solution for short-range interconnects in data centers and high-performance computing environments.

Advantages

This passive DAC cable offers reliable connectivity with minimal power consumption, hot-swappable capability, and compliance with industry standards. It is an ideal alternative to OEM cables, ensuring seamless integration with multi-vendor equipment.

Suitable for

• Data center interconnects
• High-performance computing (HPC) clusters
• Network storage systems
• Ethernet and InfiniBand QDR networks

Key specifications

• Cable Type: Direct Attach Copper (DAC) - Passive
• Data Rate: 40 Gbps
• Ethernet Standard: 40GBASE-CR4
• Connector Type: QSFP (both ends)
• Cable Length: 3 meters (9.84 ft)
• Wire Gauge: 30 AWG
• Protocol Support: Ethernet, InfiniBand QDR
• Compatibility: Molex 74757-2301 (OEM equivalent)
• Hot-Swappable: Yes
• Compliance: RoHS, CE, FCC

Recommendations

For optimal performance, ensure your network equipment supports QSFP interfaces and 40GBASE-CR4 standards. This cable is compatible with a wide range of switches and routers from Cisco, Juniper, Mellanox, Arista, HP, Dell, and others.
