Cable SATA DeLOCK 85242 0,3m SATA 7 pines SATA 22 pines negro

This Delock SATA cable (0.3 m) connects a device with a 22-pin SATA interface to a standard 7-pin SATA port and a 2-pin power header on the motherboard. It supports SATA III data rates up to 6 Gbps and is suitable for compact installations where a short cable is required. The black cable is compatible with devices such as single-board computers that expose a combined SATA connector.

Advantages

The cable supports SATA III transfer speeds up to 6 Gbps and has metal clips on the SATA receptacles to secure reliable connections. Its 0.3 m length is convenient for tight internal layouts, and the combination of a 7-pin data connector and a 22-pin device connector plus a 2-pin power interface allows connection of non-standard or board-mounted SATA devices.

Suitable for

• Connecting 22-pin SATA devices to a motherboard SATA 7-pin port
• Compact PC builds and small form-factor systems
• Single-board computers (e.g., Banana Pi) with onboard SATA headers

Key specifications

• Cable type: SATA III
• Data transfer rate: up to 6 Gbps
• Cable length: 0.3 m
• Connector 1: SATA 7-pin
• Connector 2: SATA 22-pin
• Power connection: 2-pin motherboard power header required
• Colour: Black

How to use

Connect the 7-pin SATA plug to an available SATA port on the motherboard and align the 22-pin connector with the device's SATA interface. Attach the 2-pin power connector to the corresponding power header on the motherboard. Ensure the metal clips engage so the cable clicks into place, and route the cable to avoid strain or contact with moving parts.

Recommendations

Use this cable for short internal connections only; avoid bending the cable sharply and ensure the 2-pin power header matches the device power requirement. For reliable operation, connect and secure both data and power connectors before powering the system.
