Carcasa AWO-DVR-1 552 x 426 x 114 mm

The AWO-DVR-1 enclosure is a robust steel housing designed for secure wall-mounting of DVR/NVR recorders and network devices. With dimensions of 552 x 426 x 114 mm, it provides ample space for CCTV and security system components. The enclosure features a powder-coated finish in RAL 7035 (grey), a hinged removable door with 180° opening, and a key lock for security. Passive ventilation openings ensure adequate airflow, while multiple knock-out openings facilitate cable entry. Ideal for professional installations requiring protection and organization.

Advantages

Durable 1 mm steel construction with powder coating ensures long-lasting protection. The key lock and IP20 rating safeguard equipment from dust and unauthorized access. Easy wall-mounting and cable management simplify installation.

Suitable for

• CCTV and security system installations
• IT and network device housing
• Wall-mounted DVR/NVR recorder enclosures

Key specifications

• Product Type: DVR/NVR Enclosure
• Material: Steel (1 mm thickness)
• Colour: RAL 7035 (Grey)
• Mounting Type: Wall-mounted
• Security: Key lock (2 keys included)
• Protection Class: IP20
• Ventilation: Passive ventilation openings
• Cable Entry: Multiple knock-out openings
• Door: Hinged, removable, 180° opening angle
• Dimensions: 552 x 426 x 114 mm

Recommendations

For optimal performance, ensure the enclosure is mounted on a solid wall and that all cable entries are properly sealed. Compatible with most DVR/NVR recorders and network devices.
