Clip solar HellermannTyton HC 09-52 para cables de 5,2-7,0 mm, grosor de placa 1,0-3,0 mm, negro, PA66HIRHS, 50 uds.

Secure photovoltaic cables with precision using the HellermannTyton HC 09-52 Solar Edge Clip. Engineered for cable bundles from 5.2 to 7.0 mm and panel thicknesses from 1.0 to 3.0 mm, this clip offers tool-free installation and high UV resistance for long-term outdoor performance.

Overview

The HC 09-52 is a black edge-mount clip crafted from heat-stabilized, high-impact resistant polyamide 6.6 (PA66HIRHS). It withstands temperatures from -40 °C to +105 °C and meets UL94 V2 flammability standards, making it ideal for solar installations.

What stands out

• Tool-free edge mounting for quick and secure cable management
• High UV and corrosion resistance for outdoor durability
• Heat-stabilized material ensures performance in extreme temperatures
• Sold in a pack of 50 pieces for efficient installation

Technical details

• Product type: Solar Edge Clip
• Series: HC09
• Cable bundle diameter range: 5.2 - 7.0 mm
• Panel thickness range: 1.0 - 3.0 mm
• Material: Polyamide 6.6, high impact resistant, heat stabilized (PA66HIRHS)
• Colour: Black
• Mounting type: Edge mount
• Application: Photovoltaic (PV) installations
• UV resistance: High
• Operating temperature range: -40 °C to +105 °C
• Flammability rating: UL94 V2
• Corrosion resistance: Yes
• Installation type: Tool-free
• Product length: 28.0 mm
• Product width: 15.0 mm

Our verdict

A reliable, UV-stable edge clip that simplifies cable routing on solar panels, backed by HellermannTyton's engineering quality.
