Comprobador de cables Omnitronic LH-086 para conectores XLR y TRS

Omnitronic LH-086 is a handheld cable tester designed for checking a wide range of audio and signal cables used in studio, live and installation environments. It verifies continuity, pin-to-pin wiring and detects short circuits or reversed polarity for common connectors including 3- and 5-pin XLR, 3.5 mm and 6.3 mm TRS (mono and stereo), CAT5, DIN, RCA (Cinch) and 4- and 8-pin speaker connections. The tester is battery powered and built for portable use by musicians, technicians and audio engineers.

Advantages

The device offers convenient rotary-switch selection of connector types and shows continuity with an LED and an audible tone. It provides polarity indication and short-circuit detection, and can test signal through two banana sockets where diode-test probes can be connected. Compact dimensions and simple single 9 V block battery power make the LH-086 practical for field and studio use.

Suitable for

Key specifications

How to use

Connect the cable to the appropriate input and output connectors on the tester, select the matching connector type using the rotary switch, then observe the LED and listen for the piezo tone to determine continuity. For polarity and short-circuit checks read the indicator responses; for diode or signal-through tests attach test probes to the banana sockets as required. Replace the 9 V battery when indicator response weakens.

Recommendations

Use the LH-086 as a routine check tool before live events or recording sessions to confirm cable integrity. Store the tester in a dry case, remove the battery for long-term storage, and verify results by re-testing suspicious cables or using an alternate known-good cable for comparison.
