Conector de cable push-in MENNEKES 361 de 2 polos 24A, 450V, blanco

This MENNEKES 361 is a 2-pole push-in wire connector for solid and stranded conductors up to 2.5 mm². It handles 24 A at 450 V and works from -30°C to +105°C.

Advantages

Tool-free push-in termination speeds up installation. The polyamide housing is flame-retardant to UL94 V-2 and the copper alloy contacts provide reliable conductivity.

Suitable for

• Connecting solid and stranded copper conductors in junction boxes
• Building installation and industrial control wiring

Key specifications

• Connection type: screwless / push-in
• Number of poles: 2
• Rated voltage: 450 V
• Rated current: 24 A
• Conductor cross-section (solid/stranded): 0.5–2.5 mm²
• Stripping length: 11 mm
• Housing material: polyamide (PA)
• Contact material: copper alloy
• Colour: white
• Operating temperature: -30°C to +105°C
• Flammability rating: UL94 V-2
• Standards: EN 60998, VDE

Recommendations

Verify the conductor size and stripping length before insertion. For stranded conductors, twist the strands tightly to ensure a secure connection.
