Controlador LED MEAN WELL ELG-150-24-3Y potencia de salida 150 W IP20

The MEAN WELL ELG-150-24-3Y is an AC-DC single output LED driver combining constant-current and constant-voltage (CC+CV) regulation with active PFC. It accepts a three-wire AC input and delivers a fixed 24 V DC output at up to 6.25 A, providing a maximum output power of 150 W. The unit has IP20 protection and a cable output, designed for indoor LED lighting installations where a stable 24 V supply is required.

Advantages

This LED driver offers CC+CV operation with built-in power factor correction for improved mains compatibility and stable output delivery. Its fixed 24 V output and 6.25 A current limit simplify system design for 24 V LED modules. Compact dimensions allow straightforward installation in indoor fixtures and electrical enclosures.

Suitable for

• Indoor LED strips and 24 V LED modules
• Commercial and residential lighting fixtures
• LED retrofit projects and constant-voltage/constant-current applications

Key specifications

• Output voltage: 24 V DC
• Output current: 6.25 A (fixed CC limit)
• Output power: 150 W
• Input voltage range: 100–305 V AC
• Input: 3-wire AC with PFC
• Protection rating: IP20 (indoor use)
• Output type: cable output

How to use

Mount the ELG-150-24-3Y in a dry, ventilated indoor location and connect the three-wire AC supply according to local electrical codes. Connect the 24 V DC cable output to the LED load ensuring polarity is correct and that the total LED current does not exceed 6.25 A. Allow adequate space for ventilation and avoid installing near heat sources. Follow MEAN WELL wiring and safety instructions supplied with the unit.

Recommendations

Use this driver with 24 V LED modules or strips whose combined current draw stays within the 6.25 A limit; ensure installations are indoors (IP20) and comply with local electrical and safety standards.
