Controlador LED MEAN WELL XLG-150-24-A 150W IP20 90-305V 24V

The MEAN WELL XLG-150-24-A is an AC-DC single output LED driver that provides 150W constant power output with built-in active PFC. It accepts a wide AC input range of 90–305V and delivers a stable 24V DC output at up to 6.25A. The unit is designed for indoor installations and features a compact metal housing suitable for integration into lighting systems; IP20 protection rating applies.

Advantages

This LED driver offers constant power operation and integrated power factor correction for improved electrical performance. The compact metal design facilitates installation in confined spaces. Built-in adjustment (potentiometer) allows fine tuning of output current or voltage within the unit's specified range. The wide input voltage range supports international mains voltages.

Suitable for

• Indoor LED fixtures and luminaires
• Architectural and commercial lighting installations
• Retrofit lighting projects where a 24V DC supply is required

Key specifications

• Model: MEAN WELL XLG-150-24-A
• Output: 24V DC, up to 6.25A (150W)
• Input voltage: 90–305V AC
• Power type: Constant Power Mode, single output
• PFC: Built-in active power factor correction
• Housing: Metal, compact dimensions (approx. 63 × 180 × 35.5 mm)
• Protection rating: IP20 (indoor use)
• Adjustment: Built-in potentiometer

How to use

Mount the XLG-150-24-A in a well-ventilated indoor location, secure the metal housing and make AC input and DC output connections following local electrical codes. Use the built-in potentiometer to adjust output within the device limits as required by the LED load. Verify correct polarity and that the total LED load does not exceed 150W or 6.25A. Ensure proper grounding before powering on.

Recommendations

For reliable long-term operation, install the driver in a dry, ventilated indoor environment away from direct heat sources. Confirm compatibility with LED modules rated for 24V DC and keep the load within specified power/current limits. Follow MEAN WELL installation guidelines and local regulations when wiring and mounting.
