Controlador LED MEAN WELL XLG-200-12-A Potencia de salida 200 W IP20

The MEAN WELL XLG-200-12-A is an AC-DC single-output LED driver that provides 200 W output power in constant power mode with built-in power factor correction (PFC). It delivers 12 V DC at up to 16 A from a wide AC input range (100–305 VAC). The driver features a metal housing and compact dimensions suitable for constrained installations; the product data lists IP20 protection and a built-in potentiometer for output adjustment.

Advantages

The XLG-200-12-A offers constant power operation and integrated PFC for improved mains compatibility and efficiency. Its metal housing supports mechanical durability and thermal conduction. The built-in potentiometer allows convenient adjustment of output within the driver’s specified range, while the compact footprint eases installation in limited spaces.

Suitable for

• Indoor LED lighting modules and strips requiring 12 V DC
• Commercial and architectural lighting installations
• Retrofit and new-build applications with limited installation space

Key specifications

• Output power: 200 W
• Output voltage: 12 V DC
• Output current: 16 A (max)
• Input voltage: 100–305 VAC
• Protection rating: IP20 (as provided)
• Housing: metal
• Built-in potentiometer for output adjustment

How to use

Mount the driver in a dry, ventilated indoor location compatible with its IP20 rating. Connect the AC input to a properly rated power supply (100–305 VAC) and connect the 12 V DC output to the LED load, observing correct polarity. Use the built-in potentiometer to fine-tune the output within the driver’s allowable adjustment range. Ensure wiring and installation comply with local electrical codes and safety standards.

Recommendations

Do not expose the unit to moisture or outdoor conditions due to its IP20 rating. Verify that the combined LED load does not exceed 200 W or 16 A. Allow adequate ventilation around the metal housing to maintain thermal performance and service life.
