Convertidor DeLOCK M.2 Key B+M conector macho a ranura Mini PCIe cable flexible

The DeLOCK Converter M.2 Key B+M male to Mini PCIe Slot flexible cable adapts an M.2 Key B or Key M host interface to a Mini PCIe slot, enabling the use of Mini PCIe modules in systems with an M.2 socket. It supports insertion of Mini PCIe cards that expose USB and PCIe signals and allows common communication modules such as WLAN, Bluetooth, GNSS, 4G, 5G, HSPA and NFC to be used via the M.2 Key B or Key M connector. The cable is supplied in black and packaged in a box.

Advantages

This converter provides a flexible connection between M.2 Key B/M host interfaces and Mini PCIe cards, supporting modules with both USB and PCIe signal lines. It accepts half-size and full-size Mini PCIe modules and enables combined-function cards (for example WLAN with integrated Bluetooth) to use both functions through the M.2 interface. The compact flexible cable design simplifies installation in confined spaces.

Suitable for

• Integrating Mini PCIe wireless modules into systems with M.2 Key B or Key M connectors
• Using WLAN, Bluetooth or GNSS cards in devices that only provide an M.2 slot
• Prototyping and development where flexible placement of a Mini PCIe card is required
• Upgrading embedded systems to support cellular modules (4G/5G/HSPA) or NFC via Mini PCIe

Key specifications

• Manufacturer: DELOCK
• Model / MPN: 64221
• EAN: 4043619642212
• Function: M.2 Key B+M (male) to Mini PCIe slot adapter (flexible cable)
• Supported module interfaces: Mini PCIe modules with USB and PCIe signals
• Compatible module types: WLAN, Bluetooth, GNSS, 4G, 5G, HSPA, NFC (via Mini PCIe)
• Supported Mini PCIe card sizes: half-size and full-size
• Colour: Black
• Packaging: Box

How to use

Connect the male M.2 Key B or Key M connector of the converter to the host M.2 slot. Insert the Mini PCIe module into the converter's Mini PCIe slot and secure it according to the module's mounting provisions (screw or retention mechanism). Ensure that the module is compatible with USB or PCIe signal assignment expected by the host. Once installed, power on the system and install any required drivers for the Mini PCIe module.

Recommendations

Verify the pinout and signal support of your host M.2 socket (Key B or Key M) and the Mini PCIe module before installation to ensure compatibility. Handle the flexible cable and connectors carefully to avoid strain or damage; secure the cable to prevent movement in mobile or vibration-prone environments.
