Crown XTi 2002 - etapa de potencia de dos canales con DSP

The Crown XTi 2002 is a professional-grade dual-channel power amplifier featuring integrated DSP for precise audio control. Designed for live sound, installations, and touring applications, this amplifier delivers high power output with exceptional reliability and sound quality.

Advantages

Advanced DSP capabilities including EQ, crossovers, delay, limiter, and subharmonic synthesis provide complete system control. The lightweight Class D design ensures efficient operation and reduced rack weight. Comprehensive protection circuitry safeguards against short circuits, thermal overload, and DC faults.

Suitable for

• Live sound reinforcement
• Fixed installations in venues, houses of worship, and theaters
• Portable PA systems
• Monitor and main speaker amplification

Key specifications

• Channels: 2
• Power Output (Stereo, 2 Ohms): 1000W per channel
• Power Output (Stereo, 4 Ohms): 800W per channel
• Power Output (Stereo, 8 Ohms): 475W per channel
• Power Output (Bridge-Mono, 4 Ohms): 2000W
• Frequency Response: 20 Hz - 20 kHz (+0/-1 dB)
• Total Harmonic Distortion (THD): <0.5%
• Signal-to-Noise Ratio (SNR): >100 dB (A-weighted)
• Damping Factor: >500 (20 Hz to 1 kHz)
• Input Connectors: 2 x XLR
• Output Connectors: 2 x Speakon, 2 x Binding Post
• DSP Features: EQ, Crossovers, Delay, Limiter, Subharmonic Synth
• Control Interface: USB (for HiQnet control)
• Rack Space: 2U
• Cooling: Proportional-speed fan
• Amplifier Class: Class D
• Input Sensitivity: 1.4V RMS
• Protection Circuitry: Short-circuit, open-circuit, thermal, DC, RF

Recommendations

The Crown XTi 2002 is ideal for professionals seeking a powerful, DSP-equipped amplifier that combines high output with advanced system tuning capabilities. Its robust build and comprehensive protection ensure reliable performance in demanding environments.
