Cuadro de distribución de plástico HAGER PT 36M 3x12M N+PE IP40

For installations demanding a compact yet fully equipped enclosure, the HAGER PT 36M stands apart with its 3-row, 12-module-per-row layout and integrated N+PE terminal blocks. Unlike basic boxes that require separate neutral and earth bars, this board arrives ready for immediate wiring, saving time on site. The smoked transparent door allows quick visual inspection of circuit breakers without compromising protection, while the ABS construction keeps the unit lightweight for easy handling. Rated IP40, it is suited for indoor surface mounting in residential, commercial, and light industrial settings where dust and accidental contact need to be kept at bay. The DIN rail is pre-fitted, so modules clip in without extra hardware. With a 63A terminal capacity and 400V insulation rating, it handles typical distribution tasks with headroom to spare.

Highlights

• 36 modules across 3 rows (12 per row) for flexible circuit arrangement.
• Integrated N and PE terminal blocks simplify earthing and neutral connections.
• Transparent smoked door enables visual checks without opening the enclosure.
• Durable ABS plastic body with IK07 impact resistance for everyday robustness.
• Surface mount design with pre-installed DIN rail for fast installation.
• IP40 protection against solid objects over 1mm, suitable for indoor use.

In daily use

Electricians appreciate the logical layout: three rows give clear separation for lighting, power, and dedicated circuits, while the 12-module width accommodates RCBOs, MCBs, and other DIN devices without crowding. The terminal blocks are generously sized for 63A, accepting a range of conductor cross-sections. The smoked door hinges smoothly and can be removed if needed during wiring. Mounting is straightforward with pre-formed knockouts on top and bottom for cable entry, and the enclosure's white/grey finish blends into most utility areas. The ABS material resists scratches and minor impacts, maintaining a clean appearance over years of service. Temperature tolerance from -25°C to +60°C ensures reliable operation even in unheated garages or boiler rooms.

Full specifications

• Brand: HAGER
• Model: PT 36M
• MPN: 1101076
• EAN: 3838895571438
• Product type: Electrical Distribution Board
• Mounting type: Surface Mount
• Enclosure material: ABS Plastic
• Number of modules: 36
• Number of rows: 3
• Modules per row: 12
• Ingress protection: IP40
• Included terminal blocks: Neutral (N) and Protective Earth (PE)
• Door type: Transparent (Smoked)
• Enclosure colour: White / Grey
• Rated insulation voltage: 400V AC
• Rated current (terminal blocks): 63A
• DIN rail included: Yes
• Glow wire test: 650°C
• Impact resistance: IK07
• Operating temperature range: -25°C to +60°C
• Standards compliance: IEC 60670-24, EN 62208
• Application: Residential, Commercial, Light Industrial

Final note

The HAGER PT 36M is a practical choice for electricians who need a reliable, pre-wired distribution board that speeds up installation without sacrificing safety or clarity.
