DEHN 549051 UF caja de seccionamiento sin explosor de seccionamiento, IP67, negro

With an IP67 protection class, the DEHN 549051 UF Separation Point Box ensures reliable connections in underground earthing systems, even in harsh environments.

Overview

This separation point box is designed for use in earthing and lightning protection systems, providing a connection and test point for conductors. It is made of UV-stabilized, impact-resistant polypropylene, suitable for direct burial. The box features two main conductor clamps and two test conductor clamps, accepting round conductors up to 10 mm diameter and flat conductors up to 30 x 4 mm.

What stands out

• IP67 rated for dust and water immersion protection
• UV-stabilized, impact-resistant polypropylene construction
• Accepts round and flat conductors
• Removable, screw-fastened lid for secure access

Technical details

• Product Type: UF Separation Point Box
• Function: Connection and Test Point for Earthing Systems
• Installation Environment: Underground / Direct Burial
• Material: UV-stabilized, Impact-resistant Polypropylene (PP)
• Colour: Black
• Protection Class: IP67
• Conductor Connection Type: Screw terminals
• Max. Round Conductor Diameter: 10 mm (Rd 10)
• Max. Flat Conductor Dimensions: 30 x 4 mm (FL 30x4)
• Number of Main Conductor Clamps: 2
• Number of Test Conductor Clamps: 2
• Operating Temperature Range: -25 °C to +70 °C
• Resistance: UV-resistant, Weather-resistant, Impact-resistant
• Lid Type: Removable, Screw-fastened
• Compliance Standard: IEC 62561-5
• Special Feature: Without integrated isolating spark gap
• Application Area: Earthing systems, Potential Equalization, Lightning Protection Systems

Our verdict

A robust and reliable separation point box for underground earthing applications, offering IP67 protection and versatile conductor compatibility.
