DEHN LS B6 DSH ZP LSG interruptor automático 6A curva B 1 polo 909497

Protect your electrical circuits from overload and short-circuit currents with the DEHN LS B6 DSH ZP LSG miniature circuit breaker. This 6 A, B-characteristic, 1-pole MCB provides reliable protection for residential and commercial installations, ensuring safety and preventing damage to wiring and connected equipment.

Who is it for

Electricians, panel builders, and maintenance professionals who need a dependable, DIN-rail mountable circuit breaker for single-phase circuits with moderate inrush currents, such as lighting and socket outlets.

Main features

• Rated current: 6 A
• Tripping characteristic: B (for resistive and slightly inductive loads)
• 1-pole (1P) design
• Rated switching capacity: 6 kA according to EN 60898-1
• Mounting on DIN rail EN 60715, width 1 module (18 mm)
• Screw terminals for secure conductor connection

Specifications

• Rated voltage AC: 230 V
• Frequency: 50/60 Hz
• Energy limiting class: 3
• Degree of protection: IP20 (terminals), IP40 (installed)
• Max. conductor cross-section: 25 mm² flexible, 35 mm² rigid
• Ambient operating temperature: -25 to +55 °C

Tips

Ensure the breaker is installed by a qualified electrician and that the circuit is de-energized before installation. Select the appropriate conductor cross-section according to the load and local regulations.
