Desagüe de suelo lineal DEANTE 60 cm - Reversible

The DEANTE Linear Floor Drain 60 cm is a high-quality, reversible stainless steel drain designed for modern bathrooms and wet rooms. Crafted from AISI 304 stainless steel with a brushed finish, it offers exceptional corrosion resistance and a sleek, contemporary look. The reversible grate allows for flexible installation, and the removable siphon ensures easy cleaning and effective odor prevention.

Advantages

This floor drain combines durability with functionality. The adjustable feet simplify installation, while the 30 mm water seal provides reliable odor protection. The high flow rate of up to 50 L/min ensures efficient water drainage, and the K3 load capacity (up to 300 kg) makes it suitable for residential use.

Suitable for

• Walk-in showers
• Bathrooms
• Wet rooms
• Floor-level shower areas

Key specifications

• Length: 600 mm
• Channel width: 100 mm
• Grate width: 70 mm
• Material: AISI 304 Stainless Steel
• Outlet diameter: 50 mm (DN50)
• Flow rate: Up to 50 L/min
• Water seal height: 30 mm
• Load capacity: K3 (up to 300 kg)
• Finish: Brushed stainless steel

Recommendations

For optimal performance, ensure proper installation with a minimum depth of 60 mm. The included sealing collar and reducer (50/40 mm) facilitate connection to standard plumbing. Regular cleaning of the removable siphon is recommended to maintain hygiene and flow.
