DIGITUS Cable de parcheo slim CAT 6A F-FTP, cobre, LSZH, 0,5 m, gris

The DIGITUS CAT 6A F-FTP Slim Patch Cable is a high-performance Ethernet cable designed for professional network installations. With its slim design and robust shielding, it ensures reliable data transmission up to 10 Gigabit Ethernet, making it ideal for data centers, server rooms, and high-speed LAN applications. The cable features F-FTP (Foiled Foiled Twisted Pair) shielding to protect against electromagnetic interference, and a LSZH (Low Smoke Zero Halogen) jacket for enhanced safety in enclosed spaces.

Advantages

This patch cable offers exceptional performance and durability. The 28 AWG stranded copper conductors provide flexibility while maintaining signal integrity. Gold-plated RJ45 connectors (50µ) ensure corrosion-resistant, reliable connections. The snagless molded boot protects the connector tabs from damage during installation. With PoE support (IEEE 802.3af/at/bt), it can power devices like IP cameras and wireless access points.

Suitable for

• Data centers and server rooms requiring high-speed, reliable connections
• 10GBase-T networks in enterprise environments
• Applications where space is limited due to the slim cable design
• Installations requiring low smoke and zero halogen materials for safety

Key specifications

• Ethernet Category: Cat 6A
• Shielding: F-FTP (Foiled Foiled Twisted Pair)
• Conductor Material: Copper (Cu)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Data Transfer Rate: Up to 10 Gbps
• Bandwidth: Up to 500 MHz
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: Gold-plated (50µ)
• Cable Length: 0.5 m
• Cable Colour: Grey
• Conductor Gauge: 28 AWG
• Cable Construction: Stranded
• PoE Support: Yes (PoE, PoE+, 4PPoE)
• Wiring Standard: TIA/EIA 568B
• Boot Type: Molded, Snagless
• Outer Diameter: Approx. 3.6 mm
• Halogen Free: Yes
• Flame Retardant: Yes

Recommendations

For optimal performance in high-speed networks, pair this cable with compatible Cat 6A switches and patch panels. Ensure proper cable management to maintain signal integrity.
