DISTAR BAUMESSER CLICK-LOCK UNI BASE guía para amoladora angular

Angle grinder cutting guide base engineered for precise straight and miter cuts in tiles, stone, ceramics, and porcelain. The Click-Lock quick release system enables fast, tool-free mounting of any 115-125 mm angle grinder, while the stepless depth adjustment and 0-45° angle scale deliver repeatable accuracy. Integrated dust extraction and water cooling ports keep the work area clean and the blade cool for extended life.

Advantages

The universal clamp system fits most angle grinders with 115-125 mm discs, eliminating the need for multiple bases. Smooth gliding pads ensure effortless movement over the workpiece, reducing operator fatigue. The aluminum alloy and steel construction provides rigidity for vibration-free cuts, while the plastic components keep weight manageable. Dust extraction and water supply connections (32 mm and 16 mm respectively) allow connection to standard shop vacuums and water feeds, enabling wet or dry cutting with minimal mess.

Suitable for

• Tile setters and stone masons requiring accurate straight cuts and miters
• Renovation and flooring professionals working with porcelain and ceramic
• DIY enthusiasts tackling bathroom or kitchen tiling projects
• Workshops needing a portable, repeatable cutting solution for angle grinders

Key specifications

• Supported disc diameter: 115-125 mm
• Angle adjustment range: 0-45 degrees with precision scale
• Cutting depth adjustment: stepless
• Dust extraction port diameter: 32 mm
• Water supply connection diameter: 16 mm
• Mounting mechanism: Click-Lock quick release
• Base material: aluminum alloy, steel, plastic
• Integrated dust collection and water cooling: yes

Recommendations

For best results, pair this base with a diamond blade rated for your material and connect a shop vacuum to the dust port. When cutting porcelain or dense stone, use the water feed to reduce dust and extend blade life. Always verify the grinder's arbor size and guard compatibility before first use.
