Eaton DILMP20 bloque de contactos auxiliares (276985)

For electricians and panel builders expanding Eaton DILM contactors, the DILMP20 auxiliary contact block adds two normally open and two normally closed contacts. It mounts directly onto the front of DILM7 to DILM150 contactors, providing reliable status signalling and control circuit integration in industrial control panels.

Key specifications

• Contact configuration: 2 NO + 2 NC
• Mounting: Front mounting on Eaton DILM7 to DILM150 contactors
• Rated operational current: 4 A at AC-15, 230 V; 1 A at DC-13, 220 V
• Rated insulation voltage: 690 V AC
• Rated impulse withstand voltage: 6 kV
• Terminal type: Screw terminals
• Degree of protection: IP20 (terminals)
• Operating temperature: -25 to +60 °C
• Mechanical durability: 10 million operations
• Electrical durability: 1 million operations (AC-15, 230 V, 4 A)
• Short-circuit protection: Fuse gG/gL 10 A

Why choose it

This auxiliary contact block is engineered for dependable switching in demanding industrial environments. Its screw terminals ensure secure wiring, and the IP20 protection guards against accidental contact. With high mechanical and electrical durability, it delivers long service life and reduces maintenance needs.

Ideal use cases

• Interlocking and status feedback in motor control circuits
• Expanding control functionality of Eaton DILM contactors in machinery
• Building automation and HVAC control panels

Good to know

The DILMP20 complies with IEC/EN 60947-5-1 and VDE 0660 standards. It is suitable for use in pollution degree 3 environments. The block is designed for simple snap-on front mounting without tools, saving installation time.
