EATON FAK-S/KC11/I Interruptor de pie y de palma de mano, 1NO+1NC, 250V AC, 6A, IP67, amarillo

With an IP67-rated housing that shrugs off dust and temporary immersion, the EATON FAK-S/KC11/I foot and palm switch is built to thrive where lesser controls fail. Its mechanical lifespan exceeds 1 million operations, ensuring years of dependable service in demanding industrial environments.

Overview

This robust switch features a momentary (non-latching) operation with a contact configuration of 1 normally open (NO) and 1 normally closed (NC). Rated for 250 V AC and 6 A (AC-15), it suits a wide range of control applications. The insulated thermoplastic housing in yellow provides high visibility, while the black actuator offers clear contrast for easy identification. Cable entry is via one M20 gland, and screw terminals ensure secure wiring.

What stands out

• IP67 ingress protection: dust-tight and protected against temporary immersion.
• High mechanical durability: over 1 million operations.
• Versatile actuation: operable by foot or palm.
• Clear visual indication: yellow housing with black actuator.
• Robust construction: insulated thermoplastic material.

Technical details

• Contact configuration: 1 NO + 1 NC
• Rated operational voltage: 250 V AC
• Rated operational current: 6 A (AC-15)
• Operation type: Momentary (non-latching)
• Housing material: Insulated plastic (thermoplastic)
• Housing colour: Yellow
• Actuator colour: Black
• Cable entry: 1 x M20
• Terminal type: Screw terminals
• Mounting type: Surface mount / floor standing
• Electrical durability: > 0.5 million operations
• Operating temperature range: -25°C to +70°C
• Standards: IEC/EN 60947-5-1, VDE 0660
• Series: FAK Series

Our verdict

A rugged, high-visibility foot/palm switch that combines IP67 protection with exceptional mechanical endurance—ideal for harsh industrial control tasks.
