Eaton LSHU-E16/3-KL interruptor automático tipo E, 3 polos, 16 A, 400 V AC, 10 kA 119712

The Eaton LSHU-E16/3-KL is a 3-pole miniature circuit breaker with a rated current of 16 A and a Type E tripping characteristic. Its 10 kA breaking capacity at 400 V AC makes it suitable for protecting circuits in industrial and commercial installations where high inrush currents may occur.

Highlights

• 3-pole design for three-phase circuits
• Rated current: 16 A
• Tripping characteristic: Type E (short-circuit release 8-16 x In)
• Rated breaking capacity: 10 kA at 400 V AC
• DIN rail mounting (EN 60715)
• Screw terminals for conductors up to 25 mm²

In daily use

The LSHU-E16/3-KL offers reliable protection against overloads and short circuits. Its energy limiting class 3 ensures fast interruption and reduced let-through energy. The breaker is designed for frequent switching with a mechanical life of over 20,000 operations and an electrical life of over 10,000 operations.

Full specifications

• Number of poles: 3
• Rated current: 16 A
• Tripping characteristic: Type E
• Rated voltage: 400 V AC
• Rated breaking capacity: 10 kA at 400 V AC
• Frequency: 50/60 Hz
• Mounting: DIN rail (EN 60715)
• Terminal type: Screw terminals
• Terminal capacity: 1-25 mm² (solid/stranded)
• Degree of protection: IP20 (terminals), IP40 (with enclosure)
• Standard compliance: IEC/EN 60898-1
• Operating temperature: -25 °C to +50 °C
• Mechanical life: >20,000 operations
• Electrical life: >10,000 operations
• Energy limiting class: 3
• Module width: 3 modules (52.5 mm)
• Short-circuit release: 8-16 x In (128-256 A)
• Connection: Top and bottom

Final note

The Eaton LSHU-E16/3-KL is a robust and reliable miniature circuit breaker for demanding electrical installations.
