Eaton M22-XGWK accionamiento de selector con llave, negro, 2 posiciones, enclavado, sin tornillos, IP66 231274

The Eaton M22-XGWK stands out as a key-operated selector switch actuator engineered for industrial control and automation, offering a secure 2-position maintained switching action with a key removal position at 0. Its 22.5 mm mounting diameter and 36 x 36 mm front element make it compatible with standard panel cutouts, while the screwless connection technology simplifies installation with compatible Eaton M22 contact blocks. The black bezel and key, constructed from high-grade plastic, provide a durable and professional appearance suitable for harsh environments, with an IP66 front protection rating and an operating temperature range of -25 to 70 °C.

Highlights

• Key-operated selector switch actuator for secure, maintained 2-position control
• Screwless connection technology for quick and tool-free installation
• Front protection rating IP66 for resistance to dust and water ingress
• Wide operating temperature range from -25 to 70 °C for versatile use
• Compatible with Eaton M22 contact blocks and LED elements

In daily use

In industrial settings, the M22-XGWK provides reliable and secure switching operations. The key can be removed in position 0, preventing unauthorized changes to the switch state. The maintained (latching) action ensures the switch remains in the selected position until the key is turned again, making it ideal for applications requiring stable control states. The screwless design reduces wiring time and minimizes the risk of loose connections, while the robust construction withstands demanding conditions.

Full specifications

• Product Type: Selector Switch Actuator
• Operation Type: Key-operated
• Number of Positions: 2-position
• Switching Action: Maintained (Latching)
• Key Removal Position: Position 0
• Mounting Diameter: 22.5 mm
• Front Element Dimensions (W x H): 36 x 36 mm
• Color: Black (Bezel/Key)
• Ingress Protection (Front): IP66
• Operating Temperature Range: -25 to 70 °C
• Connection Technology: Screwless
• Series: Eaton M22
• Compatibility: Eaton M22 Contact Blocks and LED Elements
• Key Code: RONIS S1
• Number of Keys Included: 1
• Actuator Material: High-grade plastic
• Application: Industrial Control, Automation

Final note

For secure and efficient control in industrial environments, the Eaton M22-XGWK delivers reliable key-operated switching with easy installation and robust protection.
