Eaton PXL-C20/1 interruptor automático 1P C 20A 10kA 236060

Electricians and panel builders use the Eaton PXL-C20/1 to protect single-phase circuits against overload and short-circuit. This 1-pole miniature circuit breaker with C characteristic and 20 A rated current is built for DIN rail mounting in distribution boards and industrial control panels.

Key specifications

• Rated current: 20 A
• Tripping characteristic: C
• Number of poles: 1P
• Rated voltage: 230/400 V AC
• Breaking capacity: 10 kA
• Frequency: 50/60 Hz
• Energy limiting class: 3
• Mounting: DIN rail (EN 60715)
• Terminal capacity: 1–25 mm²
• Degree of protection: IP20 (terminals), IP40 (front)
• Standards: IEC/EN 60898-1
• Operating temperature: -25 to +50 °C
• Mechanical life: ≥ 20,000 operations
• Electrical life: ≥ 10,000 operations

Why choose it

The PXL series combines reliable protection with a compact design. Screw terminals accept solid or stranded conductors up to 25 mm², simplifying installation. The C curve suits general lighting and socket circuits with moderate inrush currents.

Ideal use cases

• Protection of lighting and power circuits in residential and commercial buildings
• Control panel protection for motors, heaters, and transformers
• Retrofit and new installations on DIN rail systems

Good to know

The breaker is rated for 10 kA short-circuit breaking capacity and complies with IEC/EN 60898-1. It operates reliably in ambient temperatures from -25 °C to +50 °C.
