Eaton PXL-C25/3 Interruptor automático de 25 A 3 polos con curva C 236428

Electricians and panel builders install the Eaton PXL-C25/3 in three-phase distribution boards to protect circuits against overload and short-circuit. This miniature circuit breaker (MCB) is rated for 25 A with a C tripping characteristic, making it suitable for loads with moderate inrush currents such as motors, lighting, and general power distribution.

Key specifications

• Number of poles: 3
• Rated current: 25 A
• Tripping characteristic: C
• Rated voltage: 230/400 V AC
• Breaking capacity: 10 kA
• Mounting: DIN rail

Why choose it

The PXL-C25/3 offers reliable protection with a compact design that saves space in distribution boards. Its C-curve ensures dependable operation for typical commercial and industrial applications.

Ideal use cases

• Protection of three-phase circuits in commercial buildings
• Motor control circuits with moderate inrush currents
• Distribution boards in industrial installations

Good to know

The breaker has a rated insulation voltage of 440 V and an impulse withstand voltage of 4 kV. It operates in ambient temperatures from -25 to +50 °C and has a mechanical life of over 20,000 operations.
