EATON PXL-C32/3 Interruptor automático 32A 3 polos curva C 10kA

Among miniature circuit breakers, the EATON PXL-C32/3 distinguishes itself with a robust 10 kA breaking capacity packed into a compact 3-module width, delivering dependable overload and short-circuit protection without sacrificing valuable panel space. Its C-characteristic tripping curve is precisely tuned for circuits with moderate inrush currents, making it a versatile choice for commercial and industrial distribution boards.

Highlights

• Rated current 32 A, 3-pole configuration for three-phase systems
• C tripping characteristic handles moderate inrush loads reliably
• Breaking capacity 10 kA according to IEC/EN 60898-1
• DIN rail mounting (EN 60715) for quick, tool-free installation
• Screw terminals accept solid conductors up to 25 mm² and flexible up to 16 mm²
• Energy limiting class 3 reduces let-through energy for enhanced safety

In daily use

Installed in distribution boards, the PXL-C32/3 provides dependable protection for three-phase circuits such as motors, heaters, and lighting groups. Its C-curve ensures it tolerates normal starting currents without nuisance tripping, while still responding quickly to genuine overloads and short circuits. The IP20 terminal protection and IP40 housing with cover offer safe operation in standard enclosures, and the wide operating temperature range from -25 °C to +50 °C suits challenging environments.

Full specifications

• Product type: Miniature circuit breaker (MCB)
• Series: PXL
• Number of poles: 3
• Rated current (In): 32 A
• Tripping characteristic: C
• Rated breaking capacity (Icn): 10 kA
• Rated voltage (Ue): 230/400 V AC
• Rated frequency: 50/60 Hz
• Mounting type: DIN rail (EN 60715)
• Terminal type: Screw terminals
• Terminal capacity (solid): 1-25 mm²
• Terminal capacity (flexible): 1-16 mm²
• Degree of protection: IP20 (terminals), IP40 (housing with cover)
• Standard compliance: IEC/EN 60898-1
• Energy limiting class: 3
• Operating temperature range: -25 to +50 °C
• Mechanical endurance: 20,000 operating cycles
• Electrical endurance: 10,000 operating cycles
• Pollution degree: 2
• Module width: 3 TE (52.5 mm)

Final note

With its high breaking capacity, compact footprint, and reliable C-curve performance, the EATON PXL-C32/3 is an excellent choice for protecting three-phase circuits in demanding commercial and industrial installations.
