Eaton RMQ16 accionamiento para pulsador Q18LT-GE/WB, enrasado, momentáneo, iluminado, botón amarillo, collar negro, montaje 16,2 mm 088449

Pushbutton actuator from the Eaton RMQ16 series, featuring a flush momentary action with spring return. The actuator is illuminated and designed for a 16.2 mm mounting diameter, with a yellow button and black plastic bezel.

Advantages

Compact 18 x 18 mm front design fits space-constrained control panels. The flush profile reduces accidental operation while maintaining easy access. The actuator supports illumination when paired with a compatible LED element, providing clear status indication. Durable plastic construction ensures reliable performance in industrial environments.

Suitable for

• Control panels and operator interfaces
• Machine control and automation systems
• Applications requiring a compact, illuminated pushbutton

Key specifications

• Actuator type: Flush, momentary (spring return)
• Illumination: Yes (requires separate LED element)
• Button colour: Yellow
• Bezel colour: Black
• Mounting diameter: 16.2 mm
• Front dimensions: 18 x 18 mm
• Protection rating (front): IP65
• Material (bezel and button): Plastic
• Operating temperature: -25 to +70 °C
• Storage temperature: -40 to +80 °C
• Mechanical life: > 3 million operations

Recommendations

For a complete pushbutton, combine this actuator with a contact block from the M16-K series and an LED element from the M16-LED series, both available separately.
