Eaton T0-1-15431/I1 Interruptor basculante unipolar, 20 A, IP65, negro/blanco 207070

This 1-pole toggle switch from Eaton provides reliable ON-OFF control for industrial applications, with a rated operational current of 20 A at 400 V AC. Its robust design includes a black toggle lever and white front plate, suitable for front mounting.

Advantages

The switch offers a high degree of protection (IP65 on the front) and a wide operating temperature range from -25 to +50 °C, ensuring durability in demanding environments. Screw terminals provide secure connections.

Suitable for

• Control circuits in industrial machinery
• Panel builders requiring a compact, reliable switch
• Applications needing a simple ON-OFF function with high current rating

Key specifications

• Number of poles: 1
• Switching function: ON-OFF
• Rated operational current: 20 A (AC-21A, 400V)
• Rated operational voltage: 690 V AC
• Degree of protection (front): IP65
• Mounting type: Front mounting
• Actuator type: Toggle lever
• Connection type: Screw terminals

Recommendations

Ideal for panel builders and maintenance engineers seeking a robust, high-current toggle switch with clear visual status indication.
