Eaton Z-SLS/B 35A 400V cartucho fusible D02 268991

The Eaton Z-SLS/B 35A 400V D02 fuse link provides reliable overcurrent protection for main distribution boards and SLS switch-disconnectors. Its ceramic body and visual blown-fuse indicator ensure safe and easy monitoring.

Advantages

Rated for 35 A at 400 V AC, this fuse link offers a breaking capacity of 50 kA, ensuring robust short-circuit and overload protection. The screw-in design fits standard D02 fuse bases for quick installation.

Suitable for

• SLS switch-disconnectors
• Main distribution boards
• Overcurrent protection in electrical installations

Key specifications

• Rated current: 35 A
• Rated voltage: 400 V AC
• Fuse size: D02
• Operating class: gG
• Breaking capacity: 50 kA
• Material: Ceramic
• Indicator: Visual
• Mounting: Screw-in
• Number of poles: 1
• Frequency: 50/60 Hz

Recommendations

For use with D02 fuse bases and SLS switch-disconnectors in commercial and industrial electrical distribution systems.
