Eaton Z-TN24/SS interruptor de impulso, carril DIN, 2 NO + 1 NC, 20 A, 24 V AC/DC Y7-267976

Rated for 20 A main circuit current with a 2 NO + 1 NC contact configuration, this Eaton impulse switch handles frequent switching up to 1000 operations per hour.

Overview

The Eaton Z-TN24/SS is a DIN rail mounted impulse switch (latching relay) designed for lighting and load control. It features two normally open (NO) and one normally closed (NC) contacts, with a rated current of 20 A and a control voltage of 24 V AC/DC.

What stands out

• High switching capacity: 20 A main circuit, 2000 W incandescent load
• Versatile control: 24 V AC or DC coil
• Compact: only 1 module (TE) wide on DIN rail
• Long mechanical life: 1,000,000 operations
• Wide operating temperature: -25 to +50 °C

Technical details

• Contact configuration: 2 NO + 1 NC
• Rated current: 20 A
• Control voltage: 24 V AC / 24 V DC
• Rated voltage (main circuit): 250 V AC
• Mounting: DIN rail (EN 60715)
• Number of modules: 1 TE
• Connection: screw terminals
• Degree of protection (terminals): IP20
• Switching frequency: 1000 operations/hour
• Electrical life: 100,000 operations
• Mechanical life: 1,000,000 operations
• Short-circuit withstand: 3 kA
• Power consumption (AC): 5.5 VA
• Power consumption (DC): 2.5 W
• Max. incandescent lamp load: 2000 W
• Max. fluorescent lamp load (uncompensated): 1000 VA

Our verdict

A robust and compact impulse switch for demanding lighting control applications, offering high switching capacity and long service life.
