EFB Elektronik Cable de fibra óptica a granel 9/125 µm OS1PE Negro (55448.1)

The EFB Elektronik Bulk Fibre Cable 9/125 µm OS1PE is a high-quality single-mode fibre cable designed for professional network installations. This bulk cable offers excellent performance for long-distance data transmission, ensuring reliable connectivity in telecommunications and data centre environments.

Advantages

This fibre cable provides low attenuation and high bandwidth, making it ideal for backbone and campus networks. The OS1PE grade ensures compliance with industry standards for outdoor and indoor use, while the black jacket offers durability and UV resistance.

Suitable for

• Telecommunications networks
• Data centre infrastructure
• FTTx deployments
• LAN and WAN backbone connections

Key specifications

• Fibre type: Single-mode 9/125 µm
• Fibre grade: OS1PE
• Jacket colour: Black
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Core diameter: 9 µm
• Cladding diameter: 125 µm
• Attenuation (max): ≤0.4 dB/km at 1310 nm, ≤0.3 dB/km at 1550 nm
• Bending radius: ≥10 mm (short term), ≥30 mm (long term)
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +80°C

Recommendations

For optimal performance, use with appropriate connectors and splicing tools. Ensure proper handling to avoid micro-bends. This cable is suitable for both indoor and outdoor installations when properly protected.
