EFB Elektronik Cable troncal U-DQ ZN BH OM4 12G 1x12 LC-LC 70 m Dca LSZH O8342S70OM4

Fiber optic trunk cable with 12 OM4 multimode fibers, pre-terminated with LC connectors on both ends, delivering high bandwidth for data center and backbone applications over 70 meters.

Advantages

OM4 multimode fiber supports 4700 MHz·km bandwidth at 850 nm, enabling 10G, 40G, and 100G Ethernet. LSZH jacket is halogen-free and flame retardant, with Dca fire rating for safe indoor installation. Universal cable construction suits indoor and outdoor use. Pre-terminated LC connectors save installation time.

Suitable for

• Data center backbone cabling
• High-speed LAN connections
• Indoor and outdoor fiber runs

Key specifications

• Cable length: 70 m
• Fiber type: OM4 multimode, 50/125 µm
• Connectors: LC to LC, 12 fibers
• Jacket: LSZH, halogen-free, flame retardant
• CPR fire rating: Dca
• Attenuation: < 2.3 dB/km at 850 nm, < 0.6 dB/km at 1300 nm

Recommendations

Ideal for structured cabling in data centers and enterprise networks requiring high-density, low-latency fiber links. Verify connector compatibility with your equipment.
