EFB Tira de pines PCB 20 polos, paso 2,54 mm, recta, macho, THT, serie EWLP, negra

The EFB 22020.1 is a high-quality PCB pin header designed for reliable board-to-board or wire-to-board connections. With 20 positions in a single row and a standard 2.54 mm pitch, this straight male connector is ideal for a wide range of electronic applications. Manufactured by EFB Elektronik, it features robust brass contacts with tin plating for excellent conductivity and corrosion resistance. The black PBT insulation material ensures durability and meets UL94V-0 flammability standards.

Advantages

This pin header offers secure through-hole mounting and solder termination, providing a stable and long-lasting connection. Its compact design saves space on PCBs while maintaining high reliability. The 3 A current rating and 250 V voltage rating make it suitable for many low-to-medium power applications.

Suitable for

• Prototyping and development boards
• Industrial control systems
• Consumer electronics
• Automation equipment
• Test and measurement devices

Key specifications

• Connector Type: PCB Pin Header
• Number of Positions: 20
• Pitch: 2.54 mm
• Series: EWLP
• Mounting Type: Through Hole
• Gender: Male
• Orientation: Straight
• Termination Style: Solder
• Number of Rows: 1
• Contact Material: Brass
• Contact Plating: Tin
• Insulation Material: PBT
• Current Rating: 3 A
• Voltage Rating: 250 V
• Operating Temperature: -40°C to +105°C
• Dielectric Withstanding Voltage: 1000 V AC
• Insulation Resistance: 1000 MΩ (min)
• Contact Resistance: 20 mΩ (max)
• Flammability Rating: UL94V-0
• Color: Black

Recommendations

For optimal performance, ensure proper soldering and avoid exceeding the rated current and voltage. This connector is RoHS compliant and suitable for lead-free soldering processes.
