Estación de acoplamiento para portátil Port Replicator Port Designs 901906-W USB 3.2 Gen 2 Type-C negro

The Port Designs 901906-W USB 3.2 Gen 2 Type-C docking station expands a laptop's connectivity with a compact, travel-friendly design. It supports triple Full HD video output or a single 4K display, provides up to 100W power delivery, and connects wired peripherals via a USB-C cable. The dock is compatible with both PC and Mac and includes card reader and network support for everyday workstation needs.

Advantages

This dock supports up to three simultaneous Full HD displays (or one 4K output), delivers up to 100W power to charge a connected laptop, and manages up to 11 peripherals through a variety of ports. Its compact form factor and 55 cm integrated cable make it suitable for mobile use while providing Gigabit Ethernet, SD and microSD card slots, and a mix of USB 3.0 and USB 2.0 ports for legacy and high-speed devices.

Suitable for

• Expanding laptop ports for remote or hybrid workstations
• Connecting multiple external monitors for productivity setups
• Using wired Ethernet for stable network access
• Transferring files via SD and microSD cards
• Connecting USB peripherals such as mouse, keyboard, and external drives

Key specifications

• Model: Port Designs 901906-W
• Interface: USB-C (USB 3.2 Gen 2)
• Video outputs: 1× DisplayPort, 1× HDMI, 1× VGA — up to triple Full HD or single 4K
• USB ports: 2× USB-A 3.0, 2× USB-A 2.0
• Card reader: SD and microSD
• Network: Ethernet LAN (RJ-45) — Gigabit
• Audio: 1× combined Audio/Microphone jack
• Power delivery: up to 100W
• Cable length: 55 cm (integrated)
• Colour: Black
• Weight: 0.2 kg

How to use

Connect the docking station to your laptop using the built-in USB-C cable. Attach external monitors to the DisplayPort, HDMI or VGA connectors and arrange display settings in your operating system. Plug USB devices into the available USB-A ports, insert SD or microSD cards into the corresponding slots, and connect a network cable to the Ethernet port for wired internet. If needed, connect speakers or headsets to the combined audio/microphone jack. The device is plug-and-play on most systems; check your OS display settings for multi-monitor configuration.

Recommendations

For stable multi-display performance and reliable charging, use a laptop USB-C port that supports DisplayPort Alt Mode and power delivery. When using three monitors, ensure connected displays are set to Full HD resolution to match the dock’s triple-display capability. Keep the integrated cable free from sharp bends and avoid placing heavy objects on the dock to prolong its lifespan.
