EUROLITE LED THA-230F Foco de teatro 230W RGBW LED proyector de perfil 41602170

The EUROLITE LED THA-230F Theater-Spot stands out as a professional-grade LED profile spotlight engineered specifically for theatrical and stage applications. Unlike conventional spotlights that rely on discharge lamps, this fixture employs a powerful 230W RGBW LED engine, delivering vibrant colour mixing and a crisp, defined beam without the maintenance burden of lamp replacements. Its precise optics and quiet operation make it an ideal choice for theatres, houses of worship, and live productions where colour accuracy and silent performance are paramount.

Highlights

• High-output 230W RGBW LED source for rich, saturated colours and pure whites
• Motorized focus and zoom for flexible beam shaping from tight spots to wide washes
• Quiet fan cooling system suitable for noise-sensitive environments
• DMX512 control with multiple channel modes for seamless integration
• Robust metal housing built for touring and permanent installation

In daily use

In daily operation, the THA-230F delivers consistent performance with minimal attention. The LED engine provides instant full brightness without warm-up time, and the colour mixing system allows for smooth fades and precise colour matching. The fixture's compact size and moderate weight make rigging straightforward, while the intuitive control panel and LCD display simplify addressing and mode selection. Whether used as a front light for key lighting or as an effects projector with gobos, it offers reliable, flicker-free output suitable for broadcast and video recording.

Full specifications

• Light source: 230W RGBW LED
• Beam angle: adjustable via motorized zoom (approx. 15°–30°)
• Control: DMX512, master/slave, standalone
• DMX channels: multiple modes (e.g., 4, 6, 10 channels)
• Dimming: 0–100% electronic, flicker-free
• Strobe: 1–20 Hz
• Colour mixing: RGBW, 16-bit resolution
• Housing: metal, black
• Cooling: low-noise fan
• Power supply: 100–240V AC, 50/60Hz
• Power consumption: max. 260W
• Dimensions (WxDxH): approx. 320 x 220 x 420 mm
• Weight: approx. 7.5 kg

Final note

The EUROLITE LED THA-230F Theater-Spot combines professional features with LED efficiency, offering a reliable and versatile lighting solution for demanding stage environments.
