EXSYS EX-48011 Tarjeta adaptadora Mini PCI Express a 2 puertos USB 3.2 Gen 1

Unlock 5 Gbit/s USB 3.2 Gen 1 connectivity from a Mini PCI Express slot with the EXSYS EX-48011. This half-size adapter card adds two USB Type-A ports to embedded systems, industrial PCs, and compact builds, delivering true 5 Gbps data throughput for high-speed peripherals.

Overview

The EX-48011 leverages the Renesas uPD720202 host controller to provide two SuperSpeed USB 3.2 Gen 1 ports over a Mini PCI Express 2.0 interface. It is fully backward compatible with USB 2.0 and 1.1 devices, ensuring seamless integration with existing hardware. The card supports hot-swapping and plug-and-play for effortless device connection.

What stands out

• Two USB 3.2 Gen 1 Type-A ports with 5 Gbit/s per-port throughput
• Mini PCI Express full-size form factor (51 x 30 mm) for space-constrained systems
• Renesas uPD720202 chipset ensures stable, high-performance operation
• Broad OS compatibility: Windows 2000 through Windows 10 (32/64-bit) and Linux
• Bus-powered design – no external power adapter required

Technical details

• Host interface: Mini PCI Express (PCIe 2.0)
• USB standard: USB 3.2 Gen 1 (USB 3.0 / 3.1 Gen 1)
• Maximum data transfer rate: 5 Gbit/s
• Number of USB ports: 2
• USB connector type: USB Type-A (female)
• Chipset: Renesas uPD720202
• Form factor: Mini PCI Express full-size
• Dimensions: 51 mm (length) x 30 mm (width)
• Power: via Mini PCI Express slot
• Compliance: USB 3.2 Gen 1 specification, PCI Express Base Specification 2.0

Our verdict

The EXSYS EX-48011 is a reliable, compact solution for adding high-speed USB 3.2 Gen 1 ports to Mini PCIe-equipped systems. Its proven chipset and broad OS support make it ideal for industrial and embedded applications where space and performance are critical.
