EXSYS EX-6975 Fuente de alimentación para carril DIN 120W 24V 5A Convertidor AC-DC industrial

Industrial control systems often face unstable power or space constraints. The EXSYS EX-6975 DIN rail power supply delivers a regulated 24V DC output from a universal AC input, ensuring reliable operation of automation equipment, sensors, and controllers. Its compact metal housing mounts directly onto standard DIN rails, saving panel space and simplifying installation.

Who is it for

This power supply is ideal for system integrators, panel builders, and maintenance engineers who need a robust, efficient, and safe power source for industrial machinery, building automation, or test setups. It suits applications requiring up to 120W of clean DC power with protection against electrical faults.

Main features

• Wide AC input range: 100–240V, 47–63Hz
• Stable 24V DC output, adjustable from 24V to 28V
• High efficiency >88%, reducing energy waste and heat
• Comprehensive protections: overload, overvoltage, short circuit, overtemperature
• DIN rail mountable (TS-35) with screw terminal connections
• Durable metal housing with free air convection cooling
• Certified to CE, UL, TUV, and RoHS standards

Specifications

• Output power: 120W
• Output current: 5A
• Ripple & noise: <150mVp-p
• Hold-up time: >20ms at full load, 230VAC
• Isolation voltage: I/P-O/P 3kVAC, I/P-FG 1.5kVAC, O/P-FG 0.5kVAC
• Operating temperature: -20°C to +70°C
• Storage temperature: -40°C to +85°C
• MTBF: >300,000 hours

Tips

For optimal performance, ensure adequate ventilation around the unit and derate output above 50°C ambient. Use appropriate wire gauges for screw terminals and verify the output voltage adjustment before connecting sensitive loads.
