FSAS Fujitsu Módulo riser RAID interno para servidor PRIMERGY

The FSAS Fujitsu Internal RAID Riser Module is a proprietary server riser card designed to integrate the Fujitsu PRAID CP400i RAID controller into compatible Fujitsu PRIMERGY servers. This passive PCB module provides a high-speed data path for SAS/SATA signals, connecting the RAID controller to the server motherboard and storage backplane. It is an essential component for expanding storage capabilities in enterprise environments.

Advantages

Enables seamless integration of the PRAID CP400i controller, ensuring reliable RAID functionality. The PCIe x8 interface delivers high bandwidth for demanding workloads. Compact riser design saves internal space while maintaining robust connectivity.

Suitable for

• Fujitsu PRIMERGY RX2530 M4/M5/M6/M7
• Fujitsu PRIMERGY RX2540 M4/M5/M6/M7
• Fujitsu PRIMERGY RX4770 M5/M6/M7
• Fujitsu PRIMERGY RX2520 M5/M6

Key specifications

• Product Type: RAID Riser Card
• Host Interface: PCIe x8
• Internal Connectors: 2x SFF-8643 (Mini-SAS HD)
• Form Factor: Proprietary Server Riser Card
• Compatible Controller: Fujitsu PRAID CP400i
• Part Number: S26361-F3937-L100

Recommendations

This riser module is specifically designed for Fujitsu PRIMERGY servers and is not compatible with other brands. Ensure your server model is listed in the compatibility list before purchase. For optimal performance, pair with the Fujitsu PRAID CP400i controller.
