Fuente de alimentación compacta ASUS Compact Plug 180W 20V 9A 0A001-00266400

The ASUS Compact Plug Power Supply 180W (model 0A001-00266400) is a high-efficiency AC adapter designed for select ASUS laptops, including ROG Strix, Zephyrus, and TUF Gaming series. With a compact plug form factor and robust 180W output, it delivers reliable power for demanding tasks.

Advantages

This power supply features Level VI energy efficiency, active PFC, and comprehensive protection against over-voltage, over-current, short-circuit, and over-temperature. The compact plug design saves space and reduces cable clutter, while the 1.8m DC cable and 1.2m AC cable provide flexible placement.

Suitable for

• ASUS ROG Strix laptops requiring 180W
• ASUS Zephyrus laptops requiring 180W
• ASUS TUF Gaming laptops requiring 180W
• Other ASUS laptops compatible with 20V 9A barrel connector (6.0mm x 3.7mm with center pin)

Key specifications

• Power Output: 180W
• Output Voltage: 20V DC
• Output Current: 9A
• Input Voltage: AC 100-240V, 50/60Hz
• DC Connector: Barrel 6.0mm x 3.7mm with center pin
• Efficiency: Level VI
• Color: Black
• DC Cable Length: 1.8m
• AC Cable Length: 1.2m
• Protection: Over-voltage, Over-current, Short-circuit, Over-temperature
• Power Factor Correction: Active PFC
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -20°C to 85°C
• Certifications: CE, FCC, RoHS

Recommendations

Always verify compatibility with your laptop model. This adapter is intended as a replacement or spare for original ASUS adapters with identical specifications. Ensure the connector size matches your device.
