Fuente de alimentación MEAN WELL DDR-60G-15 60W 15V 4A

The MEAN WELL DDR-60G-15 is an ultra-slim industrial DIN-rail DC-DC converter that accepts a wide input range of 9–36 VDC and provides a single regulated 15 VDC output at up to 4 A (60 W). Its compact housing and DIN-rail mounting make it suitable for space-constrained control cabinets and industrial automation equipment. The unit meets RoHS requirements.

Advantages

The converter offers a compact form factor with reliable 15 VDC output and 4 A current capability, enabling stable power delivery for connected devices. Wide input voltage range provides compatibility with various DC bus systems and battery-backed supplies. DIN-rail mounting simplifies installation in electrical cabinets, while RoHS compliance supports environmentally conscious installations.

Suitable for

• Industrial control cabinets and PLC installations
• Embedded systems and automation modules requiring 15 VDC
• Battery-backed or vehicular DC power systems with 9–36 V input

Key specifications

• Input voltage range: 9–36 VDC
• Output voltage: 15 VDC
• Output current: 4 A
• Output power: 60 W
• Mounting: DIN-rail (ultra-slim housing)
• Dimensions (W×D×H): 52.5 × 54.5 × 90 mm
• Compliance: RoHS

How to use

Mount the DDR-60G-15 on a standard DIN rail inside the control cabinet. Connect a suitable DC supply within 9–36 V to the input terminals observing correct polarity. Connect the load to the 15 VDC output terminals taking care not to exceed the 4 A rating. Verify wiring and power up the input source; the converter will regulate the output to 15 V for connected equipment.

Recommendations

Use appropriate fusing on the input side and ensure adequate ventilation around the unit. Keep the device within specified ambient temperature and load limits to maintain reliable operation and longevity.
