Fuente de alimentación MEAN WELL DDR-60L-15 60 W entrada 18-75 V salida 15 V

The MEAN WELL DDR-60L-15 is an ultra-slim industrial DC-DC DIN-rail converter that accepts a wide input range of 18–75 Vdc and provides a single regulated 15 Vdc output at up to 4 A (60 W). Its compact design (52.5 × 54.5 × 90 mm) and RoHS compliance make it suitable for space-constrained control cabinets and industrial automation installations requiring a stable low-voltage supply.

Advantages

The DDR-60L-15 offers a high input-voltage tolerance and a compact DIN-rail form factor that save panel space. It delivers a regulated 15 V output with 60 W maximum power and is designed for industrial environments. Compliance with RoHS ensures it meets common environmental standards.

Suitable for

• Industrial control cabinets and PLC systems
• Automation equipment and field controllers
• Embedded devices and instrumentation requiring 15 Vdc
• Retrofit projects where space is limited

Key specifications

• Brand: MEAN WELL
• Model: DDR-60L-15 (MPN: DDR-60L-15)
• Input voltage: 18–75 Vdc
• Output voltage: 15 Vdc
• Output current: 4 A (max)
• Output power: 60 W
• Mounting: DIN rail
• Dimensions: 52.5 × 54.5 × 90 mm
• RoHS: compliant
• EAN: 4021087050654

How to use

Mount the converter on a standard DIN rail inside the control cabinet. Connect an appropriate 18–75 Vdc source to the input terminals observing polarity, and connect the 15 Vdc output to the load, ensuring the load current does not exceed 4 A. Verify wiring and grounding according to local electrical codes before powering the unit. Allow adequate ventilation around the unit for heat dissipation.

Recommendations

Use appropriate fusing or overcurrent protection on the input side, and avoid exposing the module to excessive ambient temperatures or conductive contamination. For installations with long output wiring, check voltage drop and, if necessary, increase conductor size to maintain stable 15 V at the load.
