Fuente de alimentación MEAN WELL HDR-100-12N

The MEAN WELL HDR-100-12N is an ultra-slim AC-DC DIN-rail power supply offering 100W output power. It accepts a wide input range of 85–264VAC and provides a stable 12VDC output at up to 7.5A. The compact dimensions (70 × 54.5 × 90 mm) make it suitable for installation in control cabinets and confined spaces. This model is RoHS compliant and supplied in packs of 48 units.

Advantages

The HDR-100-12N delivers reliable 12VDC power with wide input voltage compatibility, ensuring stable operation across varying mains conditions. Its ultra-slim DIN-rail form factor saves panel space and simplifies mounting. The device meets RoHS environmental requirements and is designed for continuous industrial use within its rated limits.

Suitable for

• Industrial control cabinets and automation systems
• Building management and security equipment
• DIN-rail mounted telecom or network devices
• Applications requiring compact 12V power supplies

Key specifications

• Input voltage: 85–264VAC
• Output voltage: 12VDC
• Output current: 7.5A (max)
• Output power: 100W
• Form factor: Ultra-slim DIN-rail
• Dimensions: 70 × 54.5 × 90 mm
• Compliance: RoHS
• Pack quantity: 48 units
• Model/MPN: HDR-100-12N

How to use

Mount the MEAN WELL HDR-100-12N on a standard DIN rail inside the distribution or control enclosure. Connect the AC mains to the input terminals observing proper wiring and grounding practices. Connect the 12VDC output to the load, ensuring the total current does not exceed 7.5A. Verify correct polarity and secure terminal connections before powering on. Allow adequate ventilation and follow the manufacturer's instructions for safe operation.

Recommendations

Use within rated input and output limits, avoid overloading beyond 7.5A, maintain recommended ambient temperature and ventilation, and follow local electrical codes during installation.
