Mean Well HDR-60-24 Fuente de alimentación para carril DIN 60 W 24 V

The Mean Well HDR-60-24 is a 60 W DIN-rail power supply with a 24 V DC output. It accepts a wide input voltage range and is designed for mounting on TS35/7.5 or TS35/15 DIN rails.

Key features

• 24 V DC output, 0–2.5 A
• Input voltage: 85–264 VAC or 120–370 VDC
• DIN-rail mount (TS35/7.5 or TS35/15)
• Output voltage adjustable
• Protection: short circuit, overload, overvoltage
• Cooling by free air convection
• LED operation indicator
• Operating temperature range: -30 to +70 °C
• No-load power consumption <0.3 W
• Efficiency: 0.9
• Output tolerance: ±1%
• Ripple and noise: 150 mV
• Dimensions: 52.5 x 90 x 54.5 mm
• Compliance: LPS, UL60950-1, UL508, UL1310, EN60950-1, EN61558-2-16, EN61000-3-2
• Design refer to EN50178
• Class II insulation
• Stainless steel housing

Specifications

• Brand: Meanwell
• MPN: HDR-60-24
• Output voltage: 24 V DC
• Output current: 0–2.5 A
• Output voltage adjustment range: 21.6–29 V
• Input voltage: 85–264 VAC or 120–370 VDC
• Mounting: DIN rail TS35/7.5 or TS35/15
• Width on rail: 52.5 mm (3SU)
• Operating temperature: -30 to +70 °C
• No-load power consumption: <0.3 W
• Efficiency: 0.9
• Output tolerance: ±1%
• Ripple and noise: 150 mV
• Dimensions: 52.5 x 90 x 54.5 mm
• Protection: short circuit, overload, overvoltage
• Cooling: free air convection
• LED operation indicator
• Compliance: LPS, UL60950-1, UL508, UL1310, EN60950-1, EN61558-2-16, EN61000-3-2
• Design refer to EN50178
• Class II insulation
• Housing material: stainless steel
