Fuente de alimentación MEAN WELL SKM10C-15 10 W 15 V 36-75 V

The MEAN WELL SKM10C-15 is a compact DC-DC converter designed for PCB mounting. It accepts a wide input range of 36–75 V DC and provides a regulated single output of 15 V DC at up to 0.67 A (10 W). The module is supplied in a 1" x 1" DIP through-hole package, weighs approximately 18 g, and includes a remote ON/OFF control. The unit is RoHS compliant.

Advantages

The SKM10C-15 offers a small footprint and low weight suitable for space-constrained designs, stable 15 V output under varying input conditions, and a remote ON/OFF feature for system-level control. Its through-hole DIP package simplifies PCB assembly for mixed-technology boards. RoHS compliance supports environmentally regulated projects.

Suitable for

• Embedded systems and industrial control boards
• Telecommunications and network equipment with 36–75 V supply rails
• Compact power conversion in distributed power architectures

Key specifications

• Input voltage: 36–75 V DC
• Output voltage: 15 V DC
• Output current: 0.67 A (max)
• Output power: 10 W
• Package: DIP through-hole, 1" x 1"
• Remote ON/OFF: Yes
• Weight: approx. 18 g
• Compliance: RoHS

How to use

Mount the SKM10C-15 into the PCB using the DIP through-hole pins and follow standard soldering practices for through-hole components. Apply an input supply within 36–75 V DC to the input pins and take the regulated 15 V DC from the output pins, observing correct polarity. Use the remote ON/OFF pin to enable or disable the output according to your system control signals. Allow for appropriate layout clearance and thermal considerations when integrating the module on a populated board.

Recommendations

For reliable operation, provide input protection (fuse or surge protection) on the 36–75 V supply, maintain adequate PCB creepage and clearance for safety, and ensure the module is mounted with airflow or thermal paths suitable for the 10 W power level. Verify connection polarity and test the remote ON/OFF function during system commissioning.
