GACIA PR8NM 4P 25A 30mA tipo A dispositivo de protección diferencial (RCD) 4 polos 25A 30mA

The GACIA PR8NM 4P 25A 30mA A is a high-quality residual current device (RCD) designed for reliable protection against electric shock and fire hazards. With 4 poles, a rated current of 25A, and a rated residual operating current of 30mA, this Type A RCD is suitable for a wide range of residential and commercial applications. It complies with IEC/EN 61008-1 standards and is easy to install on DIN rails.

Advantages

This RCD offers enhanced safety with its Type A sensitivity, detecting both sinusoidal and pulsating DC fault currents. Its compact design saves space in distribution boards, and the 10kA conditional short-circuit current rating ensures robust performance under fault conditions. The device is built for durability with 10,000 electrical and 20,000 mechanical cycles.

Suitable for

• Residential electrical installations requiring earth leakage protection
• Commercial buildings and offices
• Industrial control panels
• Any circuit where protection against indirect contact and fire risk is needed

Key specifications

• Product Type: Residual Current Device (RCD)
• Number of Poles: 4-Pole
• Rated Current (In): 25 A
• Rated Residual Operating Current (IΔn): 30 mA
• RCD Type: Type A
• Rated Voltage (Ue): 230/400 V AC
• Rated Frequency: 50/60 Hz
• Mounting Type: DIN Rail
• Standards Compliance: IEC/EN 61008-1
• Tripping Characteristic: Instantaneous
• Conditional Short-Circuit Current (Inc): 10 kA
• Terminal Capacity (Solid/Stranded): Up to 25 mm²
• Terminal Capacity (Flexible): Up to 16 mm²
• Degree of Protection: IP20 (Terminals)
• Operating Temperature Range: -25°C to +40°C
• Electrical Endurance: 10,000 cycles
• Mechanical Endurance: 20,000 cycles
• Series: PR8NM

Recommendations

For optimal safety, ensure that the RCD is installed by a qualified electrician and tested regularly. Always verify compatibility with your existing electrical system before purchase.
